Null Modem Cable DB25/DB9

The most common serial interface standard is RS232 or EIA232C established by the Electronic Industries Association ( EIA). This standard specifies transmission at signal rates of 20kps or less with a 15 meter maximum distance.

  • Connects an external modem (DB25) to a PC serial port (DB9);  DB25 M/ DB9 F, DB25 M/ DB9 M, DB25 F/ DB9 F, DB25 F / DB9 M available under request.
  • Gold contact plating provides reliable connections with repeated mating cycles
  • Molded backshells provide durability and increased strength at cable entry point
  • 100% shielding throughout for protection against EMI/RFI
  • Length options are 1.5M, 3M, 5M, 7.5M, 10M, we can also meet other length you request;
  • color is gray or black
  • Regullar wiring arrangement list below, We can also offer under your wiring arrangement



DB25 / DB9 Null Modem Cable Wiring Arrangement

Wiring F

DB25

DB9

2

2

3

3

4

8

5

7

7

5

68

4

20

16

1

SHELL



Item

Description

Wiring

Length

261208-1.5

Null Modem Cable,Molded DB25 M/ DB9 F

E

1.5 M

261208-3

Null Modem Cable,Molded DB25 M/ DB9 F

3 M

261208-5

Null Modem Cable,Molded DB25 M/ DB9 F

5 M

261208-7.5

Null Modem Cable,Molded DB25 M/ DB9 F

7.5 M
